Services
FRAMECAD Structure & Detailer Training
Lgsfdesign Training Department provides training in FRAMECAD software — covering FrameCAD Detailer and FrameCAD Structure.
- Structure FrameCAD Structure
- Detailer FrameCAD Detailer
This course is a comprehensive program designed to equip individuals with the skills and knowledge to effectively utilize the FRAMECAD system for structural design and detailing. FRAMECAD is a leading provider of end-to-end steel framing solutions, offering innovative software and machinery for the construction industry.
Become a master in FRAMECAD — register for the training course today.
- Structure FrameCAD Structure
- Detailer FrameCAD Detailer
Course topics
What you'll learn
A comprehensive program for structural design and detailing with the FRAMECAD system.
Manufacture-ready detailing
Detailer converts concepts into framing layouts ready for FRAMECAD machine production.
3D model viewing
Review detailed framing plans with 3D capabilities before they hit the shop floor.
Two software packages
Train on Structure, Detailer, or the combined Structure & Detailer path.
Curriculum
Structure & Detailer
Explore the basics covered in each FRAMECAD software package.
Structure track
FRAMECAD Structure
FRAMECAD Structure makes real-time engineering calculations as designs are created — analyzing loads, deflections, and other forces — so you can optimize building code compliance while delivering best-value engineering. Based on the IntelliCAD platform, it completes over 25,000 engineering calculations per square meter of roof and walls in seconds and can improve engineering time by up to 80%.
- 25k+
- Calcs / m² in seconds
- 80%
- Faster engineering time
Register for Structure
Jump to enrollment — pick this track or Structure & Detailer.
FRAMECAD Structure Basics
- Introduction
- Border Settings
- Creating Wall Frame Layouts
- Add Openings
- Creating Truss Layout and Final Wall
- Truss Design & Joist Layout
- Wall Frame Design
- Engineering Analysis and Commands
- Importing to FRAMECAD Detailer
- Roof Panels Detailing
- Completion of Sample Project Design
Detailer track
FRAMECAD Detailer
FRAMECAD Detailer is advanced detailing software that lets a steel frame manufacturing operation design from scratch — walls, roof trusses or roof panels, and webbed sub-floors — or convert an architect’s concept into detailed building design plans ready for manufacture. It turns structural drawings into framing plans with 3D viewing, then into production with high accuracy for cold-formed steel construction.
- 3D
- Model viewing
- CFS
- Manufacture-ready detail
Register for Detailer
Jump to enrollment — pick this track or Structure & Detailer.
FRAMECAD Detailer Basics
- Machine Configuration Options
- Drafting Tools
- Software Interaction with FRAMECAD Structure
- Basic Layout, Punching Tools and Frame Scripts
- Building Wall Frames
- Assigning Properties
- Adding Openings and Triples
- Building and Modifying Trusses
- Exporting FRAMECAD Detailer Files
- Importing to FRAMECAD Detailer
- Roof Panels Detailing
Register now
Become a master in FRAMECAD
Tell us which course you want — Structure, Detailer, or both — and we’ll follow up with enrollment details.
Whether you are new to cold-formed steel workflows or already detailing for production, our training department helps your team use FRAMECAD Structure and Detailer with confidence.
-
Choose your track
Structure only, Detailer only, or the combined Structure & Detailer path.
-
Built for real projects
Learn wall frames, trusses, openings, engineering analysis, and manufacture-ready export.
-
Clear next steps
After you register, we confirm availability and share schedule and enrollment details.
Enrollment
Register for training
Full name, email, phone, and your preferred FRAMECAD course track.
